LCL filters are very commonly used in the modern renewable energy industry, and can efficiently and economically ensure and improve the feed quality from energy sources to the grid. The filters are used for filtration of the switching frequency of the invertor. When reaching the target distortion level, the filters can save considerable costs. LCL filters are typically characterized by small loss, small size, light weight, and high capacitance.
LCL filter can effectively and economically ensure and improve the feed quality from energy to power grid. The progress of power semiconductor switching device technology has promoted the rapid development of power electronic converter technology. Various converter devices based on pulse width modulation (PWM) control have emerged, such as inverter power supply, inverter and other converters, and these converters have been widely used in various fields throughout the many country. Three phase voltage source PWM rectifier has bidirectional power output and fast dynamic control response.
The current PWM rectifier adopts IGBT as the power switching device, which can achieve a high switching frequency. Generally, the switching frequency is 2kHz~15kHz. However, the high turn on and turn off frequency of power switching devices will generate higher harmonics, which will be injected into the power grid and cause harmonic pollution. In order to solve the problem of LCL filter, we usually choose LCL filter. LCL filter can select smaller inductance and capacitance value to achieve satisfactory filtering effect between kilowatts and hundreds of kilowatts.
LCL filters are very commonly used in the modern renewable energy industry, and can efficiently and economically ensure and improve the feed quality from energy sources to the grid. The filters are used for filtration of the switching frequency of the invertor. When reaching the target distortion level, the filters can save considerable costs. LCL filters are typically characterized by small loss, small size, light weight, and high capacitance.
LCL filter can effectively and economically ensure and improve the feed quality from energy to power grid. The progress of power semiconductor switching device technology has promoted the rapid development of power electronic converter technology. Various converter devices based on pulse width modulation (PWM) control have emerged, such as inverter power supply, inverter and other converters, and these converters have been widely used in various fields throughout the many country. Three phase voltage source PWM rectifier has bidirectional power output and fast dynamic control response.
The current PWM rectifier adopts IGBT as the power switching device, which can achieve a high switching frequency. Generally, the switching frequency is 2kHz~15kHz. However, the high turn on and turn off frequency of power switching devices will generate higher harmonics, which will be injected into the power grid and cause harmonic pollution. In order to solve the problem of LCL filter, we usually choose LCL filter. LCL filter can select smaller inductance and capacitance value to achieve satisfactory filtering effect between kilowatts and hundreds of kilowatts.
Features
1. Rated working voltage: 380VAC 50/60Hz
2. Rated working current: 20A to 1600A @ 40 ℃;
3. Withstand voltage test: 3000VAC 60/S (capacitance release)
4. Protection grade: IP00
5. Reactor noise: ≤ 80dB (measured at 1m from the reactor)
6. Altitude:<1000m
Environmental conditions
1. The altitude does not exceed 2000 meters
2. Temperature resistance class F (155 ℃) or above
3. The operating ambient temperature is - 25 ℃~+45 ℃, and the relative humidity is not more than 90%
Typical Applications
Oil & Gas Industry
Water and Waste Water
HVAC
Textiles
Commercial Facilities
Data Centers
Pulp & Paper
Metal Fabrication
Electroplating
Elevators and Escalators
Industrial Rectifiers
Induction Furnaces
